# PHILIPS CONSUMER ELECTRONICS, CO.
CM206
Device Type Internal CD-ROM
Interface Proprietary
Spin Rate (Read) 1x, 2x
Formats Supported Read CD-ROM (Mode 1 & Mode 2)
View Top
IMG IMG 1
+------------------------------------------------------------+
| CONNECTIONS |
|------------------------------------------------------------|
| Function | Label |
|-------------------------------+----------------------------|
| Audio line out | CN1 |
+------------------------------------------------------------+
+------------------------------------------------------------+
| MISCELLANIOUS TECHNICAL NOTES |
|------------------------------------------------------------|
| Note: The interface for this drive is proprietary with the |
| Philips Consumer Electronics, Co. CM206 Sound Card. |
+------------------------------------------------------------+
