# IBM CORPORATION
APTIVA TV CARD
Card Type TV card
Video Chip Set Unidentified
Maximum Video Unidentified
Memory
Video Types VGA
Supported
Highest Resolution 640 x 480
Supported
I/O Options TV connector, composite video in, S-video
in, audio in - right, audio in - left
Data Bus 16-bit ISA
IMG IMG 1
+------------------------------------------------------------+
| CONNECTIONS |
|------------------------------------------------------------|
| Function | Label | Function | Label |
|-----------------------+-------+--------------------+-------|
| TV connector | CN1 | Unidentified | J14 |
|-----------------------+-------+--------------------+-------|
| 40-pin connector | J4 | Audio in - right | J15 |
|-----------------------+-------+--------------------+-------|
| Composite video in | J7 | Audio in - left | J16 |
|-----------------------+-------+--------------------+-------|
| S-video in | J8 | | |
+------------------------------------------------------------+
